46AWG flame retardant flexible cable, pvc jacket flame retardant cable, 300V flame retardant flexible cable
1. Product description
46AWG flame retardant flexible cable, pvc jacket flame retardant cable, 300V flame retardant flexible cable insulation material: PVC, SRPVC, conductor: twisted, tin-plated or bare copper GN-YE conductor, outer layer 3 core or above black core white, sheath material: PVC; Application: The cable is suitable for use under moderate mechanical stress conditions. It can be used in both dry and wet environments, but can no longer be used outside. It can also be used for unforced movement. Suitable for machine tool measurement and control.This type of cable is composed of many strands of small wires, with good flexibility and bendability. It has flame retardant properties, that is, in case of fire, it can inhibit the spread of flame and reduce the damage caused by fire.
Feel free to contact with us, if you ever needed to consider your wire harness solution.
| Product Name |
46AWG flame retardant flexible cable, pvc jacket flame retardant cable, 300V flame retardant flexible cable |
| Product certification | Pass ISO13485,ISO9001,UL and ROHS2.0 certification |
| Product application | Industrial, comsumer electrics, medical, etc |
| Temperature |
-20℃~80℃ |
| Oil resistance | 60 ℃ or 80 ℃ Oil |
| Flame rated | VW-1,FT1,FT2,IEC60332-1-3 |
| Voltage withstand test | AC 2.0kV/1min |
|
Free sample |
Accept |
| Percent of original elongation | 1~2 weeks |
| After-sales service | Authentic guaranteed, factory outlets center |
3. Picture of real products
4. Application area
Due to the very small wire diameter of 46AWG cable, it is very common for use in miniature electronic devices and high-density electronic components. The cables are flexible and bendable to accommodate compact and complex circuit layouts. Applications can be found in computer, communication, consumer electronics, medical equipment, automotive electronics and other fields.
5. Feature
I: Excellent insulation performance
II: Extensively oil resistant
III: Excellent flexibility
6. Main products
I: Wiring harness of industrial control equipment:
Power wiring harness, signal wiring harness, control wiring harness, data wiring harness, video wiring harness, motor wiring harness, debugging wiring harness, cabinet wiring harness.
II: Medical equipment wire harnesses:
Endoscope wire harness, infusion pump power cord, ECG lead wire, monitor cable, electric operating table wire harness, electric knife wire harness and mechanical arm wire harness.
III: New energy wire harnesses:
Charging harness, energy storage harness, electric vehicle harness, navigation harness, automotive harness, instrument panel harness, sensor harness, compressor harness.
